INCAN Grinding Rolls & Bullring Segments
• Hardness: HRc60 - HRa94
Mechanical Properties
- Yield strength : > 230 MPa
- Macro - Hardness : 45 - 58 HRC
- Micro - Hardness of Sintered Hard Elements granules : About 94
- Wear resistance : 15 times more than High Chromium (Cr25) Alloys
- Elongation : About 5%
Benefits of INCAN Rolls and Tables
- Long Services Life: Service life is engineered to customer's outage requirements, with a minimum of 4 times higher than similar high chromium wear parts.
- High Output: The exposed Sintered Hard Elements have a very strong milling action which increases the output and efficiency of the mills.
- Energy Efficiency: Higher output and less operating resistance due to minimal wear reduces the total cost of milling
- Reduce Labor Costs and Mill Downtime: The maintenance interval of pulverizing mill is engineered to be a minimum of 4 times more than current wear life, due to the increase of the wear parts lifetime
- More Revenue: The reduced down time of mills using Sintered Hard Elements in to wear parts results in increased production and sales
- Cast INCAN plates are extremely ground and gouge abrasion resistant.
- The plates are engineered to provide varying service life depending upon customer requirements.
- They can be welded or bolted on surface as easily as mild steel.
- Installation labour costs are greatly reduced as a result of fewer installations.
- Production is increased as a result of fewer shutdowns for replacement.
